18650 battery safety helmet welding equipment
Price range: 300,000-500,000
Power: 150W
Warranty period: 2 years
Brand: Jinghai Laser
18650 battery cap welding laser equipment adopts automatic welding system, manual loading and unloading automatic conveying system, equipment system includes battery hopper, cap loading rotating disk High-speed galvanometer system, welding rotating disk, and other auxiliary systems, good welding process, fast speed,
Application description
18650 battery cap welding laser equipment adopts automatic welding system, manual loading and unloading automatic conveying system, equipment system includes battery hopper, cap loading rotating disk, high-speed galvanometer system, welding rotating disk, and other auxiliary systems, welding process is good, fast, each bell can weld 200-300 18650 battery cap processing, It saves a lot of labor costs and production costs, and is widely used in cylindrical battery manufacturers.
This equipment is applied to 18650, but can be upgraded according to different user needs, and the application range can be extended to 21700,32650 and other types of cylinder cell cap welding.
Laser application
Functional characteristics
System specification
The welding system component configuration: fiber laser, battery hopper, cap rotating disk, high-speed galvanometer welding system, battery welding rotating disk, CCD HD camera, automatic control system. (Welding work needs are different, the configuration will have
add or delete).
Equipment system workflow:
1. Manually discharge all the electric cells on the upper hopper, and discharge them to the conveyor belt one by one through the gravity and transmission arrangement correction mechanism.
2. Manually pour all caps directly into the rotating disc, and the rotating disc will also correct the arrangement of caps through its automatic operation.
3, when the battery is transported from the output belt to the corresponding position of the rotating disk, the magnetic mechanism will put the cap directly on the battery.
4. When the battery cell with the cap is rotated to the welding position, it will press the cap through the double pressure mechanism on the side, and output the laser through the high-speed galvanometer system, so as to realize the welding of the cap.
5, the welded cell through the rotating disk feeding mechanism directly out of the rotating disk, so as to achieve the feeding.
